SonicWALL NSA Network Security Appliance Series
Comprehensive Next-Generation firewall protection against an array of attacks.
Achieve a deeper level of security with the SonicWall Network Security Appliance (NSA) Series of next-generation firewalls. NSA Series appliances integrate automated and dynamic security capabilities into a single platform, combining the patented1 SonicWall Reassembly Free Deep Packet Inspection (RFDPI) firewall engine with a powerful, massively scalable, multi-core architecture. Now you can block even the most sophisticated threats with a multi-engine sandbox (Capture ATP), an intrusion prevention system (IPS) featuring advanced anti-evasion capabilities, SSL decryption and inspection, and network-based malware protection that leverages the power of the cloud.
Centralized control over your next-generation security
Achieve a deep level of security with a single firewall appliance. NSA Series firewalls consolidate intrusion prevention; gateway anti-virus and anti-spyware; network-based malware protection; and application intelligence and control. You can also add bandwidth management; application blocking; and connectivity and security capabilities such as a multi-engine sandbox (Capture APT), SSL VPN, IPSec VPN, content filtering, anti-virus and anti-spam.
Around-the-clock protection from the latest daily threats
Safeguard your organization around the clock with the sophisticated security capabilities of NSA Series firewalls. The RFDPI engine inspects every byte of every packet and scans all network traffic — regardless of port or protocol. Real-time TLS/SSL decryption and inspection enables you to visualize and control application traffic as it crosses the network, and NSA Series firewalls have access to a continually updated cloud database that has more than 12.6 million variants of malware to protect your organization from the most recent threats.
Enhanced network performance
Give your organization the performance it needs to grow. NSA Series firewalls surpass traditional single-core and ASIC processors, delivering a multi-core design that ensures deep-packet inspection while scaling easily for future growth.
Low cost of ownership
Lower your TCO with easy deployment, configuration and maintenance. The intuitive design and superior power efficiency of NSA Series firewalls make it easy to achieve deep security.
NSA Model Lineup:
The SonicWALL NSA 2600 is designed to address the needs of growing small organizations, branch offices and school campuses. Learn more about the NSA 2600 here!
Secure your growing small to medium-sized organization with the SonicWALL NSA 3600 Next-Generation Firewall with enterprise-class features and uncompromising performance. Learn more about the NSA 3600 here!
Secures your growing medium-sized organization with the SonicWALL NSA 4600 Next-Generation Firewall with enterprise-class features and uncompromising performance. Learn more about the NSA 4600 here!
Secure your growing mid-size organization with the SonicWALL NSA 5600 Next-Generation Firewall with enterprise-class features and uncompromising performance. Learn more about the NSA 5600 here!
Secure your emerging large organization with the SonicWALL NSA 6600 Next-Generation Firewall featuring enterprise-class features and uncompromising performance. Learn more about the NSA 6600 here!
|Models:||NSA 2600||NSA 3600||NSA 4600||NSA 5600||NSA 6600|
|SonicOS Version||SonicOS 6.2.2|
|Security Processing Cores||4 x 800 MHz||6 x 800 MHz||8 x 1.1 GHz||10 x 1.3 GHz||24 x 1.0 GHz|
|10 GbE Interfaces||-||2 x 10-GbE SFP+||4 x 10-GbE SFP+|
|1 GbE Interfaces||8 x 1 GbE||4 x 1-GbE SFP, 12 x 1 GbE||8 x 1-GbE SFP, 8 x 1 GbE
(1 LAN Bypass pair)
|Managment Interfaces||1 GbE, 1 Console|
|Memory (RAM)||2.0 GB||4.0 GB|
|Expansion||1 Expansion Slot (Rear)*, SD Card*|
|Firewall Inspection Throughput1||1.9 Gbps||3.4 Gbps||6.0 Gbps||9.0 Gbps||12.0 Gbps|
|Full DPI Throughput2||300 Mbps||500 Mbps||800 Mbps||1.6 Gbps||3.0 Gbps|
|Application Inspection Throughput2||700 Mbps||1.1 Gbps||2.0 Gbps||3.0 Gbps||4.5 Gbps|
|IPS Throughput2||700 Mbps||1.1 Gbps||2.0 Gbps||3.0 Gbps||4.5 Gbps|
|Anti-Malware Inspection Throughput2||400 Mbps||600 Mbps||1.1 Gbps||1.7 Gbps||3.0 Gbps|
|IMIX Throughput3||600 Mbps||900 Mbps||1.6 Gbps||2.4 Gbps||3.5 Gbps|
|SSL Inspection & Decription (DPI SSL)2||200 Mbps||300 Mbps||500 Mbps||800 Mbps||1.3 Gbps|
|VPN Throughput3||1.1 Gbps||1.5 Gbps||3.0 Gbps||4.5 Gbps||5.0 Gbps|
|Connections per Second||15,000/sec||20,000/sec||40,000/sec||60,000/sec||90,000/sec|
|Maximum Connections (SPI)||225,000||325,000||400,000||562,500||750,000|
|Maximum Connections (DPI)||125,000||175,000||200,000||375,000||500,000|
|SonicPoints Supported (Maximum)||32||48||64||96||128|
|Single Sign On (SSO) Users||30,000||40,000||50,000||60,000||70,000|
|VPN||NSA 2600||NSA 3600||NSA 4600||NSA 5600||NSA 6600|
|IPSec VPN clients (Maximum)||10 (250)||50 (1,000)||500 (3,000)||2,000 (4,000)||2,000 (6,000)|
|SSL VPN licenses (Maximum)||2 (250)||2 (350)||2 (500)||2 (1,000)||2 (1,500)|
|Encryption/Authentication||DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography|
|Key Exchange||Diffie Hellman Groups 1, 2, 5, 14|
|Route-Based VPN||RIP, OSPF|
|Networking||NSA 2600||NSA 3600||NSA 4600||NSA 5600||NSA 6600|
|IP Address Assignment||Static (DHCP PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP Relay|
|NAT Modes||1:1, many:1, 1:many, flexible NAT (overlapping IPS), PAT, transparent mode|
|Routing Protocols||BGP, OSPF, RIPv1/v2, static routes, policy-based routing, multicast|
|QoS||Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p|
|Authentication||XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix|
|VoIP||Full H323-v1-5, SIP|
|Standards||TCP/IP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3|
|Certifications||VPNC, ICSA Firewall, IPv6 (Phase 2)|
|Certifications Pending||FIPS 140-2, Common Criteria NDPP|
|Common Access Card (CAC)||Supported|
|Hardware||NSA 2600||NSA 3600||NSA 4600||NSA 5600||NSA 6600|
|Power Supply||200W||Single, Fixed 250W|
|Fans||Dual, Fixed||Dual, redundant, hot swappable|
|Input Power||100-240 VAC, 60-50 Hz|
|Max Power Consumption (W)||49.4||74.3||86.7||90.9||113.1|
|Form Factor||1U Rack Mountable|
|Dimensions||1.75 x 10.25 x 17 in (4.5 x 26 x 43 cm)||1.75 x 19.1 x 17 in (4.5 x 48.5 x 43 cm)|
|Weight||10.1 lb (4.6 Kg)||13.56 lb (6.15 Kg)||14.93 lb (6.77 Kg)|
|WEEE Weight||11 lb (5.0 Kg)||14.24 lb (6.46 Kg)||19.78 lb (8.97 Kg)|
|Shipping Weight||14.3 lb (6.5 Kg)||20.79 lb (9.43 Kg)||26.12 lb (11.85 Kg)|
|Major Regulatory||FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI, CU|
|Environment||32-105 F, 0-40 deg C|
Services & Add-Ons:
Advanced Gateway Security Suite (AGSS)
Leverage SonicWall Advanced Gateway Security Suite (AGSS) to deliver a multi-engine sandbox, powerful anti‐virus, anti‐spyware, intrusion prevention, content filtering, as well as application intelligence and control services. An upgrade over CGSS, this package features Capture Advanced Threat Protection (ATP), a multi-engine sandbox that runs and inspects suspicious files, programs and code in an isolated cloud-based environment.
Comprehensive Gateway Security Suite (CGSS)
Get the most from your deep packet inspection firewall with the SonicWall Comprehensive Security Suite (CGSS) subscription. CGSS includes gateway anti-virus, anti-spyware, intrusion prevention, application intelligence and control service, content/URL filtering and 24x7 support. Combine security, productivity and support in a single, bundled solution that lowers TCO.
Gateway Security Services
Enable your business firewall to provide real-time network threat prevention with SonicWall gateway anti-virus, anti-spyware, intrusion prevention and application intelligence and control. Block the latest blended threats — including viruses, spyware, worms, Trojans, software vulnerabilities and other malicious code. Guarantee bandwidth prioritization and ensure maximum network security and productivity with granular policies for both groups and users.
Capture Advanced Threat Protection
The cloud-based SonicWall Capture Advanced Threat Protection Service scans a broad range of files to detect advanced threats, analyzes them in a multi-engine sandbox, blocks them prior to a security verdict, and rapidly deploys remediation signatures. The result is higher security effectiveness, faster response times and a lower total cost of ownership.
Content Filtering Services
Gain a cost-effective, easy-to-manage way to enforce protection and productivity policies, and block inappropriate, unproductive and dangerous web content in educational, business or government environments. SonicWall Content Filtering Service lets you control access to websites based on rating, IP address, URL and more. You get the ideal combination of control and flexibility to ensure the highest levels of protection and productivity, which you can configure and control from your network security appliance, eliminating the need for a costly, dedicated filtering solution. Extend enforcement of your internal policies to devices located outside the firewall perimeter by blocking unwanted internet content with the content filtering client.
Content Filtering Client
Extend the enforcement of web policies in IT-issued devices outside the network perimeter. Although it doesn’t require a firewall, it can be optionally coupled with SonicWall Content Filtering Service as an ideal combination to keep students and employees off of dangerous or non-productive websites by switching to cloud-enforced policies even when they are using roaming devices.
Benefit from advanced technical assistance and ongoing software and firmware updates with SonicWall Dynamic Support. The service includes:
- Telephone and web-based support 24x7
- Direct access to highly-trained senior support engineers
- Advance exchange hardware replacement in the event of a failure
- Access to electronic support tools
TotalSecure Hardware & Services Bundle
Enjoy the convenience and affordability of deploying your firewall as a SonicWall TotalSecure solution. This combines the hardware and services needed for comprehensive network protection from viruses, spyware, worms, Trojans, key loggers and more — without the complexity of building your own security package.
Comprehensive Anti-Spam Service
Block threats from your email server and stop spam at the gateway by adding SonicWall Comprehensive Anti-Spam Service (CASS) to your SonicWall firewall. Rapidly deploy your spam firewall software with one-click activation of up to 250 users.
Enforced Client Anti-Virus and Anti-Spyware Software
Execute an innovative, multi-layered, anti-virus internet security strategy with SonicWall firewalls and Enforced Client Anti-Virus and Anti-Spyware software. You get SonicWall Reassembly-Free Deep Packet Inspection anti-malware at the gateway, and enforced anti-virus protection at the endpoints. You can redirect any user with a non-compliant endpoint to a web page to install the latest Enforced Client Anti-Virus and Anti-Spyware software. Provide automatically updated security definitions to the endpoint as soon as they become available. Plus, you can automate enforcement to minimize administrative overhead.
Download the SonicWALL NSA Series Datasheet (.PDF)
